All New - Royal Duch Gazelle: Ultimate C5 HMB
All New - Royal Duch Gazelle: Ultimate C5 HMB
Gazelle Ultimate C5 HMB (2027): Premium Dutch Design Meets Effortless Commuting
The 2027 upgrade to the Ultimate C5 is the next step up in HMB (hybrid mountain bike) eBikes. Building on two previous generations of this model, this eBike is a refined, comfortable eBike that redefines the perfect commuter vehicle. Wide tires, suspension seatpost, and air-sprung forks give a smooth ride on any terrain.
This is a premium model that perfectly blends sporty urban functionality with touring comfort; the Ultimate C5 has a low-maintenance beltdrive and an active riding position. Built for navigating city streets and exploring scenic trails, this versatile e-bike is designed to meet the needs of discerning riders across Canada.
2027 Innovations
This year's model has been overhauled to give you an even better riding experience than with the 2026 Ultimate C5.
- An air-shock fork is installed by default, with much more travel and noticably improved suspension than the old coil fork.
- Integrated decceleration brake lights are installed, clearly indicating to cyclists and drivers behind you whenever the brake is used.
- The central display is now mounted inside the stem, which is much easier to read while riding and even stronger than before.
- The maximum loading capacity, which is now 331 lb.
Key Highlights
- Bosch Performance Line Motor with 75 Nm of torque for powerful, smooth assistance (20 mph)
- 540 Wh integrated battery for extended rides and long-lasting performance. This can be upgraded to 800 Wh, or supplemented with the PowerMore 200 Wh range extender.
- Shimano Nexus 5-Sp Beltdrive for low maintenance and clean shifting across any terrain
- Premium Shimano Deore disc brakes for smooth, responsive braking
- Wide tires, front air suspension fork, and adjustable stem for enhanced comfort
- Elegant aluminum frame with integrated battery and cables for a sleek, stylish appearance
This new Gazelle Ultimate C5 HMB is the updated flagship model from Royal Dutch Gazelle, embodying the perfect synergy between design, comfort, and performance. Available now at Reckless Shipyards, this e-bike is ideal for riders across Canada who demand the best in quality and style. Whether you're rediscovering your city or exploring new paths, the Gazelle Ultimate C5 HMB delivers an unmatched cycling experience.
Power & Performance
The Bosch Performance Line Motor powers the Ultimate C5 with an upgraded 75 Nm of torque and adaptive support that feels natural and responsive. It delivers the right amount of power for all your journeys.
The system integrates seamlessly with the Bosch eBike Flow App, offering:
- Personalized motor tuning
- Ride analytics and activity tracking
- Navigation and range prediction
- Security and system updates over the air
Share
Couldn't load pickup availability

Specifications
Battery
Charger: Bosch Compact Charger, 2A
eBike Battery Watt Hours: 540 Wh
Battery Position: integrated in the frame
Frame and Fork
Frame: Stable aluminum frame with 70.5° headset angle and 71,5° saddle tube angle for sporty cycling characteristics. Battery, motor and cables harmoniously integrated into the frame. High-quality finish with attention to detail.
Sitting Position: Active
Frame cables integrated: Yes
Fork: SR Suntour NVX32 Air, Telescope, air
Fork travel: 80 mm
Fork lockout: Yes
Rear carrier: aluminum MIK HD system carrier
Wheels And Brakes
Tire Front: Schwalbe The Green Marathon, 55-622, 80% recycled and renewable materials
Tire rear: Schwalbe The Green Marathon, 55-622, 80% recycled and renewable materials
Front rim: Ryde ZAC 25, double-walled aluminum for extra strong and efficient cycling performance
Rear rim: Ryde ZAC 25, double-walled aluminum for extra strong and efficient cycling performance
Front hub: Shimano HB-TC500
Rear hub: Shimano Nexus 5
Front brake: hydraulic disc brake, Shimano BR-MT200, 180 mm, 2 piston
Rear brake: hydraulic disc brake, Shimano BR-MT200, 160 mm, 2 piston
Shifter: Enviolo Twist Pure - Manual
Front chain wheel: 55 Gates CDC
Rear chain wheel: 24 Gates CDC
Gear: Enviolo Trekking Manual
Drivetrain: belt
Chain/belt: Gates CDC
Motor
Motor: Bosch Smart System Performance Line
Ebike Engine Position: Mid
Ebike Max Speed mph: 20
Engine Max Torque (Nm): 75
Full Spec
Charger: Bosch Compact Charger, 2A
eBike Battery Watt Hours: 540 Wh
Battery Position: integrated in the frame
Frame: Stable aluminum frame with 70.5° headset angle and 71,5° saddle tube angle for sporty cycling characteristics. Battery, motor and cables harmoniously integrated into the frame. High-quality finish with attention to detail.
Sitting Position: Active
Frame cables integrated: Yes
Fork: SR Suntour NVX32 Air, Telescope, air
Fork travel: 80 mm
Fork lockout: Yes
Rear carrier: aluminum MIK HD system carrier
Tire Front: Schwalbe The Green Marathon, 55-622, 80% recycled and renewable materials
Tire rear: Schwalbe The Green Marathon, 55-622, 80% recycled and renewable materials
Front rim: Ryde ZAC 25, double-walled aluminum for extra strong and efficient cycling performance
Rear rim: Ryde ZAC 25, double-walled aluminum for extra strong and efficient cycling performance
Front hub: Shimano HB-TC500
Rear hub: Shimano Nexus 5
Front brake: hydraulic disc brake, Shimano BR-MT200, 180 mm, 2 piston
Rear brake: hydraulic disc brake, Shimano BR-MT200, 160 mm, 2 piston
Shifter: Shimano Nexus 5
Front chain wheel: 46 Gates CDC
Rear chain wheel: 34 Gates CDC
Gear: Shimano Nexus 5
Drivetrain: belt
Chain/belt: Gates CDC
Handlebar: aluminum, slightly curved
Stem: Adjustable stem with Intelli-mount interface for mounting your smartphone
Grips: Ergon GP1-L ergonomic, plastic handlebar grips with ergonomic form for a better distribution of pressure
on the hands
Brake levers: Shimano BL-MT200
Seatpost diameter: 31,6 mm
Suspension: Yes
Saddle: Selle Royal Essenza Plus Gel
Motor: Bosch Smart System Performance Line
Ebike Engine Position: Mid
Ebike Max Speed mph: 20
Engine Max Torque (Nm): 75
Front light: Herrmans MR9
Front light lux: 60
Front light energy source: battery
Rear light: Spanninga Commuter Glow
Rear light energy source: battery
Lock: Axa Imenso L
Kickstand: Ursus Mooi, drop-down rear stand
Maximum weight (lbs): 331 lbs
Manufacturer Warranty
Warranty on your Gazelle bike
Gazelle provides up to a ten-year warranty on material and manufacturing defects on the frame and non-suspension front forks covering normal treatment, use, and maintenance. There is a five-year warranty on suspension front forks. A five-year warranty period applies for paintwork on the frame and the front forks. Parts on your bicycle are covered by a two-year warranty subject to normal use and maintenance.
You can also see Royal Dutch Gazelle's FAQ about their Manufacturer Warranty
