Marin 2023 Alpine Trail E2 – Ultimate All-Mountain Electric Bike
The Marin 2023 Alpine Trail E2 is built to elevate your all-mountain and enduro experience, merging cutting-edge technology with rugged durability. Designed for the rider who seeks versatility, control, and performance on technical terrains, this eMTB delivers power and stability with precision. With a robust Shimano motor, top-of-the-line suspension components, and a meticulously designed alloy frame, the Alpine Trail E2 is your companion for conquering the most challenging trails. Let us break down what makes this bike a standout in the all-mountain e-bike category.
Frame: Series 4 Alloy for Robust and Responsive Performance
At the heart of the Alpine Trail E2 is its Series 4 Alloy Frame, engineered to deliver maximum durability, responsiveness, and control. The frame features a 150mm MultiTrac suspension, providing exceptional shock absorption and stability whether navigating rocky descents or tackling steep climbs. The frame's battery and charging port integration ensure a sleek, streamlined appearance while maintaining optimal weight distribution for improved balance and maneuverability.
The 148mm rear thru-axle and built-in rear speed sensor enhance tracking precision and control, crucial for technical and fast-paced riding. The frame's thoughtful design is compatible with modern MTB components, allowing riders to customize their setup for an ideal riding experience. Built to withstand the rigours of aggressive trail riding, the Series 4 frame keeps the Alpine Trail E2 responsive and reliable on any adventure.
Suspension: Fox Performance Elite Components for Smooth Control
The Alpine Trail E2 comes equipped with the Fox 38 Performance Elite fork, which offers 160mm of travel. This top-tier suspension fork provides superior absorption, ensuring that the front wheel maintains consistent contact with the ground, even on the roughest terrain. The Fox DHX2 Performance Elite rear shock complements this setup, featuring low-speed compression and rebound adjustment. With a 205x65mm trunnion mount, this shock offers customizable tuning options, allowing riders to dial in the suspension for optimal control and comfort across various trails.
The precise suspension setup ensures that the Alpine Trail E2 remains stable and controlled, whether descending challenging sections or climbing technical inclines. By fine-tuning the rear shock's performance, riders can adapt their bike to suit their riding style and trail conditions, making every ride smooth and controlled.
Motor: Shimano Steps EP801 – Power Meets Precision
The Alpine Trail E2 is powered by the Shimano Steps EP801 Drive Unit, which delivers 250W of power and an impressive 85Nm of torque. This motor is designed to provide consistent and responsive assistance, ensuring riders have the power needed for steep climbs and technical ascents. The EP801 system adapts intuitively to rider input, offering a seamless and natural pedal-assist experience that enhances trail performance without feeling overpowered.
This powerful motor setup allows the Alpine Trail E2 to easily conquer demanding trails while maintaining a smooth, controlled ride. Its intelligent design keeps the bike's weight low and centralized, which is critical for achieving balanced and agile handling on technical terrain.
Battery: Shimano BT-EN806 – Long-Lasting Power for Extended Rides
The Alpine Trail E2 is powered by the Shimano BT-EN806 internal battery, which provides 630Wh of energy capacity. This battery allows for extended riding sessions and has a range that supports long adventures on various trail conditions. The battery is securely integrated into the frame is downtube, preserving the bike's aesthetic while optimizing weight distribution to maintain stability and balance.
The battery is designed for easy charging, with a reliable Shimano EC-E6002 charger included. This setup ensures that riders can recharge efficiently, preparing for the next adventure with minimal downtime. With its high-capacity design, the battery enables riders to explore further and tackle challenging trails with confidence.
Drivetrain: Shimano XT 12-Speed – Precision Shifting for Every Trail
The Alpine Trail E2 features a Shimano XT 12-speed drivetrain, providing precise and reliable gear changes across diverse terrains. The Shimano SLX 12-speed shifter ensures quick and accurate shifting, while the SunRace 12-speed cassette (11-51T) offers a wide gear range suitable for both climbs and high-speed descents. The drivetrain’s setup guarantees riders have the right gear for every situation, maximizing efficiency and performance on technical sections and open trails.
The Alpine Trail E2 offers a smooth and intuitive riding experience with the Shimano drivetrain seamlessly integrating with the motor system. The precise and responsive gear changes allow riders to maintain momentum and adapt quickly to varying trail conditions, enhancing overall ride quality.
Braking System: TRP DH-R Evo Hydraulic Brakes – Ultimate Stopping Power
Control is crucial on technical trails, and the Alpine Trail E2 is equipped with TRP DH-R Evo 4-piston hydraulic disc brakes, ensuring robust and consistent stopping power. The bike features 203mm front and rear rotors, delivering enhanced heat dissipation and reliable braking performance during long descents. The metallic brake pads offer excellent durability and responsiveness, providing superior modulation and control when tackling steep and technical sections.
With its robust braking system, the Alpine Trail E2 gives riders the confidence to navigate challenging terrain, knowing they have the stopping power necessary to maintain control and safety.
Wheels and Tires: Mullet Setup for Traction and Agility
The Alpine Trail E2 employs a mullet wheel setup, with a 29-inch front wheel and a 27.5-inch rear wheel. This configuration combines the stability and speed of a larger front wheel with the maneuverability and traction of a smaller rear wheel, making the bike ideal for technical trail riding. The Vee Tire Co. Attack HPL tire in the front (29x2.5") and the Crown Gem tire in the rear (27.5x2.8") are both tubeless compatible, providing excellent grip and durability on rough terrain.
This wheel and tire setup offers the perfect blend of stability, traction, and agility, ensuring that the Alpine Trail E2 performs well across various trail types and conditions.
Cockpit and Control: Ergonomic and Adjustable for Trail Dominance
The Alpine Trail E2 cockpit is designed for precision and comfort. The Marin Trail Bar features an 800mm width, offering a stable and controlled position for navigating technical trails. Combined with the Marin CNC stem and Marin Grizzly lock-on grips, the handlebar setup ensures a secure grip and comfortable riding posture, even during long and demanding rides.
The bike also includes an X-Fusion Manic dropper seat post with adjustable travel options depending on frame size. This feature allows riders to quickly and easily adjust their saddle height when transitioning between climbs and descents, enhancing control and stability and ensuring that riders remain comfortable and focused on the trail.
Additional Features and Technology
The Alpine Trail E2 comes with several advanced features that enhance the overall riding experience:
- Shimano SC-E600 display for real-time speed, assist level, and battery life information.
- Shimano E-TUBE app compatibility for ride customization, performance tracking, and firmware updates.
- CushCore inserts and tubeless-compatible rims provide added traction and protection against punctures, making the bike more resilient on technical terrain.
The Ultimate All-Mountain eMTB for Trail Enthusiasts
The Marin 2023 Alpine Trail E2 is engineered for riders who demand versatility, power, and precision on the trails. With its high-performance Shimano motor, advanced suspension components, and thoughtfully designed frame, the Alpine Trail E2 delivers a top-tier trail experience that combines power, control, and agility. Perfect for technical descents, steep climbs, and long adventures, this bike ensures that every ride is exhilarating and controlled.
Why Choose the Marin 2023 Alpine Trail E2?
Suppose you are a trail rider seeking an eMTB that offers robust performance, exceptional control, and the versatility needed to tackle a variety of terrains. In that case, the Alpine Trail E2 is your perfect match. With a powerful Shimano motor, precision drivetrain, and advanced suspension system, this bike is built to excel in all-mountain conditions, providing an unparalleled riding experience.
Share
Couldn't load pickup availability
Specifications
Battery
BT-EN806 Internal 630Wh
Frame and Fork
Frame - Series 4 Alloy Frame, 150mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
Fork - Fox 38 Performance Elite, 160mm travel, 29" , 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender
Wheels And Brakes
Brakes Front - TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor
Brakes Rear - TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor w/ Speed Sensor
Wheels - Front: Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible;
Rear: Marin Aluminum Double Wall, 27.5" Diameter, 38mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible
Tires - Front: Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Rear: Vee Tire Co. Crown Gem, 27.5x2.8”, TACKEE Compound, Tubeless Compatible
Motor
Crankset - Shimano XT M8150, 160mm Length, 38t Chainring
Motor - Shimano Steps EP801 Drive Unit, 250W, 85Nm
Full Spec
FRAME
Series 4 Alloy Frame, 150mm MultiTrac Suspension, Integrated
Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
FORK
Fox 38 Performance Elite, 160mm travel, 29" , 110x15mm
Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender
SHOCK
Fox DHX2, Performance Elite, Low Speed Compression and
Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount, S/M
Spring Rate = 350lb, L/XL Spring Rate = 450lb
RIMS
Front: Marin Aluminum Double Wall, 29" Diameter, 32mm
Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible; Rear: Marin
Aluminum Double Wall, 27.5" Diameter, 38mm Inner Rim Width, Sleeved Joint,
Disc Specific, Tubeless Compatible
HUB
REAR
Forged Aluminum, 148x12mm, Disc, 32H
HUB
FRONT
Forged Aluminum, 110x15mm, Disc, 32H
SPOKES
14g Black Stainless Steel
TIRES
Front: Vee Tire Co. Attack HPL, 29x2.5", Top 40
Tubeless Compatible, Rear: Vee Tire Co. Crown Gem, 27.5x2.8”, TACKEE Compound,
Tubeless Compatible
DERAILLEUR
REAR
Shimano XT 12-Speed, SGS
SHIFT
LEVER
Shimano SLX 12-Speed, I-Spec EV
CRANKSET
Shimano XT M8150, 160mm Length, 38t Chainring
MOTOR
Shimano Steps EP801 Drive Unit, 250W, 85Nm
CHAIN
KMC E12S, eMTB-Specific Chain
CASSETTE
SunRace 12-speed, 11-51
BRAKES
FRONT
TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm
Rotor
BRAKES
REAR
TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm
Rotor w/ Speed Sensor
BRAKE
LEVERS
TRP DH-R Evo
HANDLEBAR
Marin Trail Bar, 35mm Clamp, 7000 Alloy Bar, 800mm Length,
20mm Rise, 5 Degree Up, 8 Degree Back
STEM
Marin CNC, 35mm Length, 35mm Bar Bore
GRIPS
Marin Grizzly Lock On
HEADSET
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel,
Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm
SADDLE
Marin eMTB Saddle
PEDALS
Marin MTB Plastic
BATTERY
Shimano BT-EN806, Internal 630Wh
DISPLAY
Shimano SC-E600
SWITCH
SW-EN600L Left Hand Switch for Assist Mode Change
EXTRAS
Shimano Battery Charger EC-E6002, Shimano CS-EN800
Chainguide, CushCore, 29" Pro Front, Plus Rear, with CushCore Valve Stems,
Marin Tire Sealant 250ml, Squeeze Top with Valve Core Removal Tool Cap
Manufacturer Warranty
Limited Warranty
Marin Mountain Bikes, Inc. ("Marin") warrants to the original retail purchaser ("you") that the Marin product for which you received this warranty is free from defects in material and workmanship for the periods set forth on the below warranty table.
FRAMES Warranty Period
(From date of purchase)
- Carbon Fiber Frames and Forks: 5 Years
- Rigid Frames and Forks: Lifetime
- Full Suspension Frames: 5 Years
Complete Bicycle
The complete bicycle is warranted for one year (from date of purchase), including all original parts on the bicycle except tires, tubes, chains and other wear & tear items. Paint and decals are covered under this warranty.
This warranty period starts from the date of original retail purchase, and is valid only in North America. For warranty periods in other countries, please contact the distributor in your country. The warranty is only valid if the bicycle is purchased from, and assembled by, an authorized Marin dealer.
Warranty Limitations
This warranty does NOT cover suspension forks, and rear shocks on full suspension bikes. These items are covered by the suspension component manufacturer’s warranty. Please contact the suspension component manufacturer for any warranty needs.
This warranty is only offered to the original retail purchaser of the product, and is not transferable to a subsequent purchaser. Marin's sole obligation under this warranty is to either, at its discretion:
- Repair the claimed defect at no charge.
- Exchange the product with a product that is new or which is at least functionally equivalent to the original product.
- Offer a credit amount, determined by Marin, towards the purchase of a new product. Marin must be notified in writing of any claim under this warranty within 60 days of any claimed lack of conformity of the product.
- You may be responsible for some labor charges at your local bike shop, or some shipping charges, including return shipping if your bike is determined not to be a warranty.
The duration of any implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise, on this product shall be limited to the duration of the express warranty set forth above. In no event shall Marin be liable for any loss, inconvenience or damage, whether direct, incidental, consequential or otherwise, resulting from breach of any express or implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to this product, except as set forth herein. Some states or countries do not allow limitation on how long an implied warranty lasts and some do not allow exclusions or limitations of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights, which may vary, from location to location. This warranty will be interpreted pursuant to the laws of the United States. The original English language version/meaning of this warranty controls over all translations and Marin is not responsible for any errors in translation of this warranty or any product instructions.
No company or persons (including employees or agents of Marin) are authorized to modify, enlarge or extend this warranty in any way or to make any other warranties, expressed or implied on behalf of Marin. This warranty is not intended to confer any additional legal, jurisdictional or warranty rights to you other that those set forth herein or required by law. If any portion of this warranty is held to be invalid or unenforceable for any reason, such finding will not invalidate any other provision.
Useful Product Life
Bicycles have an unquantifiable useful product life. The useful life span of a bicycle is affected by riding style, riding conditions, frame material and construction, and other factors. The warranty period offered by Marin does not guarantee that the bicycle will last forever, or for the life span of the original purchaser. Bicycles should be inspected regularly by an authorized Marin dealer, or qualified bicycle technician to identify any issues, which could lead to a failure. Whether a failed frame will be covered by this warranty, or not, will be determined solely by Marin Bikes, based on an evaluation of the failure, useful life, and any other relevant factors.
To Obtain Warranty Service: In order to exercise your rights under this limited warranty, the complete bicycle must be presented to an authorized Marin dealer for inspection, together with a receipt, bill of sale and other appropriate written proof of purchase, which identifies the bicycle by serial number. Any labor, postage, insurance, or shipping costs incurred in sending your product for service are the responsibility of the owner. Marin will not be responsible for products lost or damaged in shipping.
Warranty Determination: Once received by Marin or Authorized Marin Warranty Center, the product will be inspected to determine if it is covered by the Marin warranty. Only Marin or an Authorized Marin Warranty Center may determine if a product is warrantable. If the product is not covered under warranty, all replacement, repair, labor, and shipping costs are responsibility of the customer. Marin cannot return un-repairable unwarranted products to the consumer if they are unsafe to use in their unrepaired condition.
At no time may any retailer or distributor make representations of what is covered or not covered under this warranty without express written permission from Marin. Should a retailer or distributor replace product before consulting Marin, it is at the sole discretion of the retailer or distributor, and may not be reimbursed by Marin. When a product or part is exchanged, any replacement item becomes property of the customer and the returned product becomes the property of Marin, which may destroy it.
Warranty Exclusions
This warranty does not cover the following:
- Products that have been modified, neglected or poorly maintained, used for commercial purposes, misused or abused or involved in accidents. It is your responsibility to regularly examine the product to determine the need for normal service or replacement.
- Damage occurring during shipment of the products (such claims must be presented directly to the shipper).
- Products sold or distributed by Marin, which are covered by another sellers’ warranty; this Marin warranty does not extend, modify or replace any other warranty.
- Products whose serial number or other identifying marks (such as decals) have been altered, defaced or removed.
- Products that are purchased used, or in not-new condition without original packaging.
- Damage to products resulting from improper assembly or repair (or the techniques used), the use or installation of parts or accessories not compatible with the original intended use of the product, or the failure to follow the product warnings, installation and usage instructions.
- This warranty does not apply if the original product decals are removed
Suspension Setup
-
REAR SHOCK SETUP
Recommended Sag = 30%/19.5mm
Step 1: Set correct pressure in rear shock.
Step 2: Sit on the bike and cycle the suspension (*with correct riding gear).
Step 3: Reset O-ring and sit on the bike, DO NOT BOUNCE, carefully step off.
Step 4: Measure sag (from o-ring to seal of shock), If it does not match the bike’s recommended sag in millimeters repeat process.
Step 5: Adjust rebound setting to ensure proper control.
-
FORK SETUP
Marin recommends that all bikes front and rear suspension feel balanced
Step 1: After rear sag is set follow the recommended pressure from the fork manufacturer.
Step 2: Bounce evenly up and down on the bike, cycling the suspension up and down to make sure both front and rear suspension feel balanced, if the front does not match the rear add or release pressure.
Step 3: Once the bike feels balanced adjust the rebound damping to ensure proper control.
